Fitment guide

Porsche 911 991 GTS Wheel & Tire Fitment Guide

Originally published | 09/20/2022
Updated | 02/28/2024

Do you want more performance out of your 2015-2019 Carrera GTS or Carrera 4 GTS or change up the overall aesthetic of the car with a new set of wheels? Look no further than this Porsche 911 991 GTS Wheel & Tire Fitment Guide. We have the fitment information you need to best suit your needs and use case all while decreasing rotational and unsprung mass. We are shedding this weight with a set of Forged VS-5RS and EC-7RS while increasing wheel width providing even more sidewall support to extract even more performance. Unlock the full potential of your GTS with a set of Apex wheels in a fitment below.

Brake Clearance Information

In the engineering phase of wheel development we 3D scan factory brakes and review 2D aftermarket brake templates in order to optimize our barrel profiles and spoke curvatures. As a result, our wheels offer massive brake clearance so you can run the smallest possible wheel diameter.

* The factory 6 piston 410mm PCCBs require 20" wheels for proper clearance. Read our article for more info.

Rear Axle Steering (RAS) Clearance

All 19" and 20" APEX wheels are optimized to clear rear axle steering (images at bottom of guide).

Available Wheel Designs

Bolt Pattern

5x130

Center Bore

71.6mm

Lug Seat

R14 Ball Seat

Thread Pitch

M14x1.5mm

Performance Street and Track Wheel Fitment

Wider fitments for enhanced performance

  • Grey Porsche 911 - VS-5RS in Anthracite
  • Black Porsche 911 - EC-7RS in Race Silver
  • Grey Porsche 911 - VS-5RS in Brushed Clear
  • White Porsche 911 - VS-5RS in Anthracite
  • Green Porsche 911 - EC-7RS in Anthracite
  • Grey Porsche 911 - VS-5RS in Satin Black

Our most popular fitments for the 991 Carrera GTS, suitable for those weekend drives or occasional track day. A great way to reduce unsprung mass, increase wheel and tire width. These are generally bolt on solutions but some tire configurations could require light suspension or alignment modifications.

5 Lug Wheels

  • Front Wheel Size: 19x9” ET50
  • Rear Wheel Size: 19x12” ET46
    • Available in: EC-7RS & VS-5RS
    • Popular fitment

Tires

  • APEX Staff Pick:
    • Front Tire Size: 265/35-19
    • Rear Tire Size: 325/30-19
    • Typically a direct fit but camber plates may be required for tire compounds that run wide
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: Goodyear Eagle Supercar 3 (220 TW), Continental Extremecontact Force (220 TW)
    • R-Compound: Nankang AR-1 (100 TW), Michelin Cup 2 (180 TW), Toyo R888R (100 TW)
    • Semi-Slick: Hoosier R7 & A7(40 TW)
  • Alternative #1:
    • Front Tire Size: 255/35-19
    • Rear Tire Size: 315/30-19
    • Direct fit
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: No options currently available
    • R-Compound: Michelin Cup 2 (180 TW)
  • Alternative #2:
    • Front Tire Size: 245/35-19
    • Rear Tire Size: 305/30-19
    • Direct fit
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: Nankang CR-S (200 TW), Goodyear Eagle Supercar 3 (220 TW), Falken RT660 (200 TW)
    • R-Compound: Goodyear Eagle Supercar 3R (100 TW), Nankang AR-1 (100 TW), Michelin Cup 2 (180 TW), Toyo R888R (100 TW)

5 Lug Wheels

  • Front Wheel Size: 19x9.5" ET45
  • Rear Wheel Size: 19x12"ET46
    • Available in: VS-5RS

Tires

  • APEX Staff Pick:
    • Front Tire Size: 265/35-19
    • Rear Tire Size: 325/30-19
    • Camber plates are required
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: Goodyear Eagle Supercar 3 (220 TW), Continental Extremecontact Force (220 TW)
    • R-Compound: Nankang AR-1 (100 TW), Michelin Cup 2 (180 TW), Toyo R888R (100 TW)
    • Semi-Slick: Hoosier R7 & A7(40 TW)
  • Alternative #1:
    • Front Tire Size: 255/35-19
    • Rear Tire Size: 305/30-19
    • Camber plates may be required
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Summer: Yokohama AD08R (200 TW)
    • R-Compound: Michelin Cup 2 (180 TW)
  • Alternative #2:
    • Front Tire Size: 255/35-19
    • Rear Tire Size: 315/30-19
    • Camber plates may be required
    • Max Performance Summer: No options currently available
    • Extreme Performance Summer: No options currently available
    • R-Compound: Michelin Cup 2 (180 TW)

5 Lug Wheels

  • Front Wheel Size: 20x9" ET44
  • Rear Wheel Size: 20x12" ET47
    • Available in: VS-5RS
    • Popular fitment

Tires

  • APEX Staff Pick:
    • Front Tire Size: 245/35-20
    • Rear Tire Size: 305/30-20
    • Direct Fit
    • Factory GTS & Turbo tire sizes
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: Nankang CR-S (200 TW), Michelin PS Cup 2 240 Connect (240 TW)
    • R-Compounds: Michelin PS Cup 2 (180 TW), Michelin PS Cup 2 R (140 TW), Pirelli Trofeo R (60 TW), Dunlop Sport Maxx Race 2 (80 TW)
    • Semi-Slick: Hoosier R7 (40 TW)
  • Alternative 1:
    • Front Tire Size: 255/35-20
    • Rear Tire Size: 315/30-20
    • Direct Fit
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: Michelin PS Cup 2 240 Connect (240 TW)
    • R-Compounds: Michelin PS Cup 2 (180 TW), Michelin PS Cup 2 R (140 TW) (60 TW), Toyo R888R (100TW)
    • Semi-Slick: No options currently available
  • Alternative 2:
    • Front Tire Size: 265/35-20
    • Rear Tire Size: 325/30-20
    • Typically a direct fit, but these tires are a touch taller front and rear in comparison to stock and may require camber plates.
    • Max Performance Summer: No options currently available
    • Extreme Performance Summer: No options currently available
    • R-Compounds: Michelin PS Cup 2 (180 TW)
    • Semi-Slick: No options currently available

Centerlock

  • Front Wheel Size: 19x9.5" ET45
  • Rear Wheel Size: 19x12" ET46
    • Available in: VS-5RS
    • Front tire may lightly rub front axle lift dust boot if equipped. Our 19x9" ET47 front wheel option can be used as an alternative for additional inside clearance (no possibility of rubbing strut).

Tires

  • APEX Staff Pick:
    • Front Tire Size: 265/35-19
    • Rear Tire Size: 325/30-19
    • Typically a direct fit but camber plates may be required for tire compounds that run wide
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: Goodyear Eagle Supercar 3 (220 TW), Continental Extremecontact Force (220 TW)
    • R-Compound: Nankang AR-1 (100 TW), Michelin Cup 2 (180 TW), Toyo R888R (100 TW)
    • Semi-Slick: Hoosier R7 & A7(40 TW)
  • Alternative:
    • Front Tire Size: 255/35-19
    • Rear Tire Size: 315/30-19
    • Direct fit
    • Max Performance Summer: Michelin PS4S (300 TW)
    • Extreme Performance Summer: No options currently available
    • R-Compound: Michelin Cup 2 (180 TW)

Centerlock

  • Front Wheel Size: 20x9" ET47
  • Rear Wheel Size: 20x12" ET47
    • Available in: VS-5RS
    • Popular fitment

Tires

  • APEX Staff Pick:
    • Front Tire Size: 245/35-20
    • Rear Tire Size: 305/30-20
    • Direct Fit
    • Factory GTS & Turbo tire sizes
    • Max Performance Summer: Michelin PSS (300 TW)
    • Extreme Performance Summer: Nankang CR-S (200 TW), Michelin PS Cup 2 240 Connect (240 TW)
    • R-Compounds: Michelin PS Cup 2 (180 TW), Michelin PS Cup 2 R (140 TW), Pirelli Trofeo R (60 TW), Dunlop Sport Maxx Race 2 (80 TW)
    • Semi-Slick: Hoosier R7 (40 TW)
  • Alternative 1:
    • Front Tire Size: 255/35-20
    • Rear Tire Size: 315/30-20
    • Direct Fit
    • Max Performance Summer: Michelin PSS (300 TW)
    • Extreme Performance Summer: Michelin PS Cup 2 240 Connect (240 TW)
    • R-Compounds: Michelin PS Cup 2 (180 TW), Michelin PS Cup 2 R (140 TW) (60 TW), Toyo R888R (100TW)
    • Semi-Slick: No options currently available

Centerlock

  • Front Wheel Size: 20x9.5" ET44
  • Rear Wheel Size: 20x12" ET47
    • Available in: VS-5RS

Tires

  • Apex Staff Pick:
    • Front Tire Size: 255/35-20
    • Rear Tire Size: 315/30-20
    • Camber plates may be required
    • Max Performance Summer: Michelin PSS (300 TW)
    • Extreme Performance Summer: Michelin PS Cup 2 240 Connect (240 TW)
    • R-Compounds: Michelin PS Cup 2 (180 TW), Michelin PS Cup 2 R (140 TW) (60 TW), Toyo R888R (100TW)
    • Semi-Slick: No options currently available

Additional Resources

Rear Axle Steering Clearance Images With 19" Wheels

Big Brake Kit Clearances

We have tested many brake kits with the wheels listed in this guide. Please email us with any questions related to brake clearance, we’ll be happy to help.

Still have questions?

Fill out our Fitment Recommendation form Call us: 925-245-0773 Email us: support@apexraceparts.com
